Automatic ointment cream manufacturing plant


  • The liquid oral manufacturing plant is designed to be    operated by one operator and one helper, saving on    precious man-power costs.
  • Sugar syrup and manufacturing vessels are provided with    limpet coils for heating and cooling, designed for internal    vacuum to facilitate transfer of sugar directly from stores to    sugar syrup vessel.
  • Sugar syrup is transferred to manufacturing vessel through    online sugar syrup pre filter by vacuum.
  • Entry of all propeller agitators are from bottom through a    specially designed cartridge mechanical seal with TC/TC    seal face.
  • The advantage of the bottom propeller agitator over the    conventional agitator is that there are no vibrations of    shaft, no couplings in the drive assembly, leading to lower    maintenance cost for liquid oral manufacturing plant.
  • Pipes, pipe fittings and valves are of SS 316, seamless,    internally electropolished with DIN standard unions and    silicon Gaskets.
  • Manhole of all the vessels are equipped with davit fitting    and the cover of the manhole slides instead of being

Capacities of ointment manufacturing plant available are

  • 20 kgs
  • 50 kgs
  • 100 kgs
  • 200 kgs
  • 300 kgs
  • 500 kgs
  • 1000 kgs
  • 2000 kgs
  • 3000 kgs
